024A Met-One Wind Direction Sensor
TABLE 8-1. Met-One Parts List Reproduced by
Campbell Scientific, Inc.
Item Part No. Description. Qty./Assy
1 102105 Vane Assembly 1
2 101685-1 Wind Dir. Support 1
3 101049-2 Label, Wind Dir. 1
4 101789 Label, Caution 1
5 860015 Screw, Shoulder 1
6 601100 Screw, Pan Hd Ph, 2-56x3/16 3
7 601680 Scrw, Set A/H, 8-32x3/8 2
8 101687 Label, Met-One 1
9 102017 Assy, Potentiometer 1
10 980495 Wire, 22Ga, Yel 1
11 980450 Wire, 22Ga, Blu 1
12 980475 Wire, 22Ga, Orn 1
13 995425 Loctite 222 A/R
14 500280 Connector, 6 Pin 1
15 995100 Adhesive, Epoxy A/R
16 995060 Adhesive, Silicone 5ml
17 510020 Cap 1
18
19
20
21 101806 Assembly, Cable Ref
22 101699 Assy Instructions Ref
23 101706 014 & 024 Installation Ref
24 101697 Wir. Diagram Ref
25
26 601850 Scrw, Cap A/H SS 10-32x5/8 1
16
