16 | SAMLEX AMERICA INC.
SectIOn 5 | Specifications
PARAMeteR MSK-135 MSK-90
SoLAR ARRAY
NoMINAL MAXIMUM PoWer AT
STC, Pmax 135W
(3x 45W Modules in parallel
90W
(2x45W Modules in parallel)
MAXIMUM PoWer VoLTAGe,
Vmp 17.4V 17.4V
MAXIMUM PoWer CUrreNT, Imp 7.74A
(2.58A per 45W Module)
5.16A
(2.58A per 45W Module)
oPeN CIrCUIT VoLTAGe, Voc 21.6V 21.6V
SHorT CIrCUIT CUrreNT, Isc 8.52A
(2.84A per 45W Module)
5.68A
(2.84A per 45W Module)
TYPe of CeLLS / SIZe Polycrystalline; 156mm X 156mm / 6.14 x 6.14 in
effICIeNCY 16.8%
NUMber of CeLLS 36 Cell per 45W Module
MAXIMUM SYSTeM VoLTAGe 1000 VDC
oPerATING TeMPerATUre - 40°C to +85°C / - 40°f to +185°f
INGreSS ProTeCTIoN (IP) rATING IP 65 (Waterproof)
STANDArD TeST CoNDITIoNS
(STC) for SoLAr MoDULe Irradiance Level: 1000W/m 2
Spectrum: AM1.5
Cell Temperature: 25°C / 77°f
cHARGe contRoLLeR MoDeL MSK-10A
(Separate MSK-10A Charge Controller Manual is available at www.samlexamerica.com to help you
make full use of the charging system)
TYPe PWM, Series Type; PWM frequency 25 Hz
MAXIMUM oPeN CIrCUIT
VoLTAGe (Voc) of SoLAr ArrAY 50V
MAXIMUM SHorT CIrCUIT
CUrreNT Isc of SoLAr ArrAY /
MAXIMUM CHArGING CUrreNT 10A
NoMINAL bATTerY VoLTAGe 12V / 24V Auto sensing: < 18V sensed as 12V
and > 18V is sensed as 24V.
bATTerY TYPe Lead Acid: flooded, Sealed AGM, Sealed Gel Cell
INGreSS ProTeCTIoN (IP) rATING IP 30 (NoT waterproof. Install in dry environment)
otHeR coMPonentS / PARAMeteRS
fuse and Mating Connector for
battery (Attached to battery Ter-
minals of Charge Controller) Fuse:
Automotive blade fuse Type ATC, 10A
Mating connector for Battery cable:
50A, Anderson Type Sb-50 compatible, 2-Pole Connector
