6 Slip the center of the transformer onto the crossbar nipple.
Secure the transformer to the ceiling by reattaching the inside
nut and washer to the crossbar nipple.
1D
INSIDE NUT
WASHER
12 Slip the stud in the transformer housing through the hole in
the dome cover marked with a silver dot.
Reattach the three screws to the side of the transformer to
secure the dome cover in place.
1E
10
9
8
13
1F
8 Connect the neutral power line wire to the white transformer
wire with a wire nut.
Connect the hot power line wire to the black transformer
wire with a wire nut.
Connect the fixture to a suitable ground according to local
electrical codes.
Feed the aircraft cable through the small holes in the dome
cover from the inside of the cover.
9
11
10
13
7
11
11
11
AIRCRAFT
CABLE
12
STUD SCREW
