LBL Lighting MEZZO GPCF User Manual
Mezzo grande pendant, Compact fluorescent), Install the mounting plate
1
Install the Mounting Plate
Remove the mounting plate from the canopy by
removing the three screws on the canopy with the Allen
wrench provided.
MOUNTING
PLATE
CANOPY
Installation Instructions for
Mezzo Grande Pendant
(Compact Fluorescent)
980MEZZOGPCF
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is suitable for damp locations.
This instruction shows a typical installation.
Suspension
1.0
LP773_CF
1A
1
1B
2
SCREW
ALLEN
WRENCH
#8-32 SCREW
Install the mounting plate to the electrical box with the
two provided #8-32 screws.
2
2
MOUNTING
PLATE
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
