If necessary, loosen the set screw on the hub with an Allen
wrench to adjust the hub. Re-tighten the set screw after
adjustment.
M4 SET SCREW
2 MM ALLEN
WRENCH
Review the steps above for installing the fixture arms before
continuing.
Cut the stem down with an appropriate cutter from the top
(like a hacksaw), and deburr the cut end with a file or grinder.
Lay the stem on a flat surface. Attach a short socket arm to
the bottom hub, and pull the wire on the arm to the top end
of the stem. Cut the wire down to that length.
Remove the arm from the hub, and lay it next to the other
short arms. Measure and cut the remaining wires to the same
length and strip the last 1/4” of each wire.
Repeat steps A-D above for the long-length arms on the
middle hub, and the long arms on the top hub.
Shortening the Chandelier (Optional)
CUT
HERE
6
4B
4C
A
B
C
D
E
5
5
