4
3C
10 2 8
2 9
Connect the crossbar and the fixture ground wire to a
suitable ground in accordance with local electrical
codes.
Connect one fixture wire to the hot power line wire with
a wire nut.
Connect the other fixture wire to the neutral power line
wire with a wire nut. 2 10
9
10
8
Place all wires, wire nut connections, and the secondary
strain relief properly inside the electrical box.
Loosen the set screw on the primary strain relief.
Align the canopy center hole with the crossbar center
hole.
Slide the canopy up against the ceiling and secure it in
place by tightening the primary strain relief into the
crossbar. Do not turn the cord.
Push the cord into the canopy and line up the marked
point on the cord with bottom of the primary strain
relief.
Tighten the plastic set screw to secure the cord.
STRAIN RELIEF
CORD
SET SCREW
3D
11
12
13
14
15
16
8
Mount the Fixture
3A
4"
Leave 6" of the cord behind the canopy for power
connections. Cut the excess cord.
From the end of the cord, strip the insulation 4" using a
sharp knife.
. Make sure not to nick the inner wires
Strip the end of the wires.
7 1
7 2
7 3
3B
10 2 4
2 5
Feed the fixture wires through the crossbar center hole
and then pull them out of the electrical box.
Install the secondary strain relief by first feeding the
power cord through it.
Snap the strain relief tab into place.
Pull the cord to take up the slack and fit the rest of the
cord in the strain relief’s openings.
2 6
2 7
4
5
6
7
7
TAB
CAUTION: Make sure to support the fixture while
installing, an assistant will be needed to complete
the remaining steps.
CAUTION: CONTINUE TO SUPPORT THE SHADE!
Do not let the fixture hang with out the completion
of the cable standoff installation (next section).
