TSC-30/IC Product Specification
1-4. General specification
Item Rating Notes
Power supply voltage DC 3.00V to 5.25V
Power consumption
125mW (standard) Power supply voltage is 5V.
30mW (standard) Power supply voltage is 3.3V.
Operating Temp
-20 ˚C to +85 ˚C
(No dew condensation)
Temperature range at storing
-40 ˚C to +125 ˚C
(No dew condensation)
Communication
scheme (serial)
Communication scheme Asynchronous, serial
Each setting is fixed
Communication rate 9600bps
Data length 8bits
Stop bit 1bit
Parity None
Communication
scheme (USB)
Transfer rate USB Specification2.0 Full Speed
Transfer mode
Control transfer (command)
Interrupt transfer (coordinate)
Operation frequency 6MHz Fixed to 6MHz
Coordinate output rate (point / second)
(1) Point mode
(2) 30p/s
(3) 50p/s
(4) 80p/s (5) 100p/s
(6) 130p/s (7) 150p/s
Point Mode: Only when touch screen is
input, pen-down ID is sent once. After
input ends, no pen-up ID is sent.
Linearity error ±3 LSB
Input response time 10ms (TYP)
For coordinate mode, 150p/s,
Serial mode
Coordinate resolution 10bit (1024×1024)
In the correction data function,
resolution follows the setting value
Dimension (mm) 12Ч12Ч1.7
