TSC-30/IC Product Specification
Power supply current
Icc1
Normal
mode
*1
Vcc=
4.0 to 5.25V
2.1
60
mA
Vcc=
3.0 to 4.0V
35
mA
Icc2
STOP mode
*2
Vcc=
3.0 to 5.25V
2.0
mA
Icc3
At USB
suspend
mode*3
Vcc=
4.0 to 5.25V
125.0
250
uA
Vcc=
3.0 to 5.25V
0.1
uA
*1: All USB difference-input circuits enabled. Leaving I/O pins open. Operating functions: CPU, Timers
*2: All USB difference-input circuits enabled. Leaving I/O pins open. Operating functions: Timers, USB
receiving. Disabled functions: CPU.
*3: All USB difference-input circuits disabled. Leaving I/O pins open. Oscillation stopped.
