TSC-30/IC Product Specification
5-2. Recommended operational conditions
Item
Symbol
Limits
Unit
Description
Minimum
Standard
Maximum
Power supply voltage
Vcc
3.00
5.00
5.25
V
Analog reference voltage
AVcc
Vcc
V
Analog reference voltage
AV
REF
2.0
Vcc
V
Analog reference voltage USB
USBV
REF
3.0
3.6
V
Vcc=3.6 to 4.0V
3.0
Vcc
V
Vcc=3.0 to 3.6V
Power supply voltage
Vss
0
V
Analog reference voltage
AVss
0
V
“H” input voltage
(Pin number 16-19, 27-50)
V
IH
0.8Vcc
Vcc
V
“H” input voltage
(Pin number 1-6, 51-64)
V
IH
0.8Vcc
Vcc
V
“H” input voltage
RESET, X
IN
, Pin number 7, 15
V
IH
0.8Vcc
Vcc
V
“H” input voltage
D+, D-
V
IH
2.0
3.6
V
“L” input voltage
(Pin number 16-19, 27-50)
V
IL
0
0.2Vcc
V
“L” input voltage
(Pin number 1-6, 51-64)
V
IL
0
0.2Vcc
V
“L” input voltage
RESET, X
IN
, Pin number 7, 15
V
IL
0
0.2V
CC
V
“L” input voltage
D+, D-
V
IL
0
0.8
V
“H” output total peak current *1
(Pin number 16-19, 27-50)
I
OH
(peak)
-80
mA
“H” output total peak current *1
(Pin number 1-6, 51-64)
I
OH
(peak)
-80
mA
“L” output total peak current *1
(Pin number 27-50)
I
OL
(peak)
80
mA
“L” output total peak current *1
(Pin number 16-19)
I
OL
(peak)
80
mA
“L” output total peak current *1
(Pin number 1-6, 51-64)
I
OL
(peak)
80
mA
“H” output total average current*1
(Pin number 16-19, 27-50)
I
OH
(avg)
-40
mA
“H” output total average current*1
(Pin number 1-6, 51-64)
I
OH
(avg)
-40
mA
“L” output total average current*1
(Pin number 27-50)
I
OL
(avg)
40
mA
“L” output total average current*1
(Pin number 16-19)
I
OL
(avg)
40
mA
“L” output total average current *1
(pin number 1-6, 51-64)
I
OL
(avg)
40
mA
“H” output peak current *2
(Pin number 16-19, 27-50)
I
OH
(peak)
-10
mA
“H” output peak current *2
(Pin number 1-6, 51-64)
I
OH
(peak)
-10
mA
