TSC-30/IC Product Specification

“L” output peak current *2

(Pin number 27-50)

I

OH

(peak)

10

mA

“L” output peak current *2

(Pin number 16-19)

I

OH

(peak)

20

mA

“L” output peak current *2

(Pin number 1-6, 51-64)

I

OH

(peak)

10

mA

“H” output average current *3

(Pin number 16-19, 27-50)

I

OH

(avg)

-5

mA

“H” output average current *3

(Pin number 1-6, 51-64)

I

OH

(avg)

-5

mA

“L” output average current *3

(Pin number 27-50)

I

OL

(avg)

5

mA

“L” output average current *3

(Pin number 16-19)

I

OL

(avg)

10

mA

“L” output average current *3

(Pin number 1-6, 51-64)

I

OL

(avg)

5

mA

Vibration frequency *4

X

IN

6.0

MHz

In USB mode

Tolerance:±0.25%

*1 The total peak output current is the absolute value of the peak currents flowing through all the

applicable ports. The total average output current is the average value of the absolute value of the
currents measured over 100ms flowing through all the applicable ports.

*2 The peak output current is the absolute value of the peak current flowing in each port.

*3 The average output current is the average value of the absolute value of the currents measured over

100ms.

*4 The duty of oscillation frequency is 50%.
