TSC-30/IC Product Specification
Ver1.2 (November 10, 2010)
1-4. General specification Operation Temp: USB changed to -20
˚C to +85 ˚C
3. Pin functions
Pin No.36 (BEEP)
“
Output frequency=2.5KHz, Output time=50ms
” was added.
Circuit Diagram
Transistor number was added. (Rev2)
Ver1.3 (May 25, 2012)
Address has changed as Tokyo office had moved
