SECTION 1. FEATURES AND SPECIFICATIONS
The Swipe & Park Hybrid Reader supports both mag-stripe and smart card technologies. For
mag-stripe cards, the unit reads tracks 1 and 2, or tracks 1, 2, and 3. For smart cards, the unit
supports ICC 8-pin contacts for ISO smart cards with flex circuit attached.
CONFIGURATIONS
Configurations are listed in Table 1-1.
Table 1-1. Configuration
Part Number Head Head Position Tracks Comments
21155001 Single Left Side 1,2,3 No Electronics
21155005 Single Left Side 1,2,3 Circuit Board with USB and RS-232 Interface
FEATURES
Features of the Swipe & Park Hybrid Reader are as follows:
• Continuous unibody chassis that consists of a magnetic swipe path in line with a smart
card reader section
• Provides for mounting a dual or triple track magnetic read head in butterfly configuration
• Contains an 8-contact smart card block in ISO location
• Smooth swipe operation with minimal interference or obstruction to the user
• Side pressure provided to keep the card from sliding away from smart card contacts
• Molded index pins provided that accurately allow for positioning of PCB
• Proper clearance provided for bowed, warped, and embossed cards
• Chassis mounting options
• Rugged design for installation in harsh and high traffic environments
And with the Electronics installed, the following additional features apply:
• On board SAM (Security Access Module)
• RS-232 and USB interfaces
• On board intelligence for transporting large blocks of data using a defined protocol and
command set
• Test LED
• Program Flash upgradeable
