Section 1. Features and Specifications
SPECIFICATIONS
Swipe & Park specifications are as shown in Table 1-2.
Table 1-2. Specifications
MECHANICAL
Dimensions:
Overall
Length
Height
Width
7.088” (177.8 mm)
2.632” (66.86 mm)
1.55” (39.4 mm)
Weight 2.31 oz (65.53 gr)
Flammability Meets UL 94V-0
ENVIRONMENTAL
Temperature:
Operating
Storage
-40
o
F to 122
o
F (-40
o
C to 50
o
C)
-40
o
F to 158
o
F (-40
o
C to 70
o
C)
Humidity:
Operating
Storage
5% to 90% non-condensing
5% to 90% non-condensing
Altitude:
Operating
Storage
0 to 10,000 ft. (0 to 3,048 m)
0 to 50,000 ft. (0 to 15,240 m)
DATA FORMAT SPECIFICATION – For PCB Model
Reader Configuration
Mag-Stripe Functions
Track 1,2,3 only
Smartcard Functions
Data Format Specification*
ISO/AAMVA/JIS formats
ISO 7810, 7811, JIS x 6302 Type 2
ISO 7816 T=0 and T=1 protocols, many popular memory cards
EMVCo Level 1 Approval
OPERATIONAL – For PCB Model
Card Speed 3 IPS (7,62 cm/sec) to 50 IPS (127, cm/sec)
Recording Method Two-frequency coherent phase (F2F)
MTBF Head: 1,000,000 passes (500,000 Insertion Cycles)
SC contacts: 1,000,000 insertions
ELECTRICAL – For PCB Model
Input Voltage
Current
12.0VDC
± 5%
500mA max, (1A with contactless smartcard option)
50mA idle, (300mA with contactless smartcard option)
* ISO (International Standards Organization), AAMVA, (American Association of Motor
Vehicle Administrators), JIS (Japanese Industrial Standard)
