IntelliStripe 60, TTL Insertion Reader
26
Table C-1. Component and Connector Descriptions
Designation
Description
Manufacturer and P/N
J1
Connector, Latch Motor, 3 pin
Molex 53048-0310
J2
Connector, Power Fail Latch
Release Capacitor, 2 pin
Molex 51021-0200 Receptacle, Mates
with Molex 52048-0210 Header. Pin 1
must connect to positive side of capacitor.
J5
Connector, Secondary Head,
7pin
Molex 53048-0710. Mates with Molex
51021-0700
J9
Connector, Primary Head
(facing opposite side of
Smartcard contacts), 7 pin
Molex 53048-0710. Mates with Molex
51021-0700
J12
Connector, I/O, 26 pin
Molex 87049-2616. Mates with Receptacle
87381-2612
J13
Connector, Smartcard Contact,
10 pin
Molex 52207-1085*. Mates with MagTek
Cable, Flex Circuit, 8 contacts (P/N
21161128), or MagTek Cable, Flex Circuit,
16 Contacts (P/N 21161122)
MH
Mounting Holes (4 places)
PL
Pin-hole Locations (2 places)
S1
Switch, Card Present
(Mechanical)
Cherry DG23-C3LA, Soldered to Board
S2
Switch, Card Seated
(Mechanical)
Cherry DG23-C2LA, Soldered to Board
S3
Switch, Card Latch Sensor
(Mechanical)
Cherry DG23-C3LA, Soldered to Board
* To insert flex cable, use a small screw driver to pull the locking tab out (on ear at each end of
the tab). Then insert the cable (Chrome side up), and push locking tab in.
