IntelliStripe 60, TTL Insertion Reader
4
ELECTRICAL
TTL Level (Non-Intelligent
PCB):
Input Voltage (J12-11):
With Latch:
No Latch:
Reader Current:
Reader Output levels:
J12-22 to J12-26
and
J12-15 to J12-16
Latch Motor Voltage:
(J12-19)
Latch Motor Current:
(J12-19)
Power-Fail Unlatch Voltage:
Power-Fail Unlatch Current:
5.0 VDC
± 5%
2.7 VDC to 5.5 VDC
Sleep Mode: 20 uA max. per read channel
Normal Mode: 2 mA max. per read channel
V
ol
= 0.4 VDC @ 2.0 mA
V
oh
= Vcc -0.5 VDC @ 2.0 mA
4.5 VDC to 8.5 VDC
Sleep Mode: 20 uA max.
Normal Mode: 300 mA nominal for 40 msec
Unlatches when the voltage at J12-11 drops below 4.5 VDC
Sleep Mode: 10 uA max.
Normal Mode: 500 mA nominal (via external capacitor).
Note: Actual current may vary based upon applied motor input voltage.
See Appendix A, Power-Fail Latch Release Assembly.
MECHANICAL
Chassis Mounting Options
Front Flange: See Section 2, Figures 2-1 and 2-3
Side Mounting Studs: See Section 2, Figures 2-1 and 2-3
Side Mounting Holes: See Section 2, Figures 2-1 and 2-3
Standoffs on Top: See Section 2, Figure 2-2
Dimensions (Core Chassis)
Overall Length:
Mounting Depth:
Height:
Width:
4.70" (119,4 mm)
3.80" (96,5 mm) when mounted with front flanges
1.30" (33,0 mm)
2.60" (66,0 mm) without mounting bosses or flanges
Weight: 120 gr (4.2 oz) without bezel, with dual head, 8 pin contact, latch, gate,
front mount flanges. 201 gr (7.1 oz) with bezel.
ENVIRONMENTAL
Temperature
Operating:
Storage:
-25
o
C to 70
o
C (-13
o
F to 158
o
F)
-40
o
C to 70
o
C (-40
o
F to 158
o
F)
Humidity
Operating:
Storage:
10% to 90% noncondensing
10% to 90% noncondensing
Altitude
Operating:
Storage:
0-10,000 ft. (0-3,048 m.)
0-50,000 ft. (0-15,240 m.)
