Section 1. Features and Specifications
3
SPECIFICATIONS
The specifications of the Reader are listed in Table 1-2. The overall dimensions are shown in
Appendix A.
Table 1-2. Specifications
DATA FORMAT SPECIFICATIONS
Reader Configuration
Track
1,2
Track 2,3
Track 1,2,3
Data Format Specifications*
ISO/ANSI/AAMVA/210bpi on TK2 formats
ISO/ANSI/AAMVA formats
ISO/ANSI/AAMVA formats
* ISO (International Standards Organization), ANSI (American National Standards Institute), AAMVA,
(American Association of Motor Vehicle Administrators)
OPERATIONAL
Card Speed: 3 IPS (7.62cm/sec) to 50 IPS (127cm/sec)
Recording Method Two-frequency coherent phase (F2F)
ELECTRICAL
Voltage Not Applicable
Current Not Applicable
MECHANICAL
Dimensions (no side pins)
Depth
Width
Height
Dimensions (side pins)
Depth
Width
Height
Dimensions (No PCB Posts)
Height
103.8 mm (4.1”)
65.8 mm (2.59”)
21.8 mm (0.86”)
103.8 mm (4.1”)
73.7 mm (2.9”)
21.8 mm (0.86”)
18.5 mm (0.729”)
Weight: 45.3 g (1.6 oz)
ENVIRONMENTAL
Temperature
Operating:
Storage:
-25 o C to 70 o C (-13 o F to 158 o F)
-40 o C to 70 o C (-40 o F to 158 o F)
Humidity
Operating:
Storage:
10% to 95% noncondensing
10% to 95% noncondensing
Altitude
Operating:
Storage:
0-10,000 ft. (0-3,048 m.)
0-50,000 ft. (0-15,240 m.)
