IntelliStripe 70 Hybrid Insertion Reader

10

Table 2-3. Track 2, 3 Head Pin Listing

Pin Signal Color

1 NC

2 NC

3 TK

2 Green

4 TK

2 Green

5 TK

3 Yellow

6 TK

3 Yellow

7 Gnd Black

Table 2-4. Track 1, 2 Head Pin Listing

Pin Signal Color

1 TK1 Red
2 TK1 Red
3 TK

2 Green

4 TK

2 Green

5 NC

6 NC

7 Gnd Black
