Figure 2-1. components of the intellistripe 70 – MagTek IntelliStripe 70 User Manual
Page 12
IntelliStripe 70 Hybrid Insertion Reader
6
96550033 rev B
PCB Mounting
Posts
PCB Mounting
Posts
Mounting Slots
Locator Pin
Card Orientation
Locator Pin
Landing
Switch
Smartcard
Flex Cable
Card
Seated
Switch
Smartcard Contacts
On Landing Switch
7 Pin
Connector
Low-Profile Beam-Style
Head Mounting
Moulded-In
Mounting Pins
Card
Catch
Figure 2-1. Components of the IntelliStripe 70
