1
SECTION 1. FEATURES AND SPECIFICATIONS
The IntelliStripe 70 is a chassis-only hybrid insertion reader, which provides magstripe and
smartcard functionality. The chassis is not equipped with electronics, which are required to
complete the magstripe and smartcard interfaces.
The reader features a low-profile mechanical footprint which is ideally suited for integration into
POS terminals, payphones, vending machines, kiosks, and fuel pumps.
CONFIGURATIONS
The part numbers, configurations, and tracks for the IntelliStripe 70 Hybrid Insertion Reader are
shown in Table 1-1.
Table 1-1. Part Numbers, Configurations, and Tracks
Part Number Configuration Track Numbers
21170001 No side pins or flange, 8 SC contacts 1 & 2
21170002 Side pins, 8 SC contacts 2 & 3
21170003 Side pins, 8 SC contacts 1, 2, 3
21170004 No side pins or flange, 8 SC contacts 2 & 3
21170005 No side pins or flange, 8 SC contacts 1, 2, 3
21170006 No side pins, with extended flex cable 1, 2, 3
21170007 Side pins, 8 SC contacts 1 & 2
21170008 Side pins, 8 SC contacts with extended flex cable 1, 2, 3
21170009 No side pins, no PCB posts, 8 SC contacts with
extended flex cable 1, 2, 3
21170010 No side pins, no PCB Posts, 8 SC contacts with
extended flex cable, no head pin cap 1, 2, 3
21170012 Side pins, 8 SC contacts with extended flex cable;
Shift-Out IntelliHead 1, 2, 3
