8
ENGLISH
Housing for big lenses
TECHNICAL SPECIFICATIONS
Housing
-External dimensions: 228x211x720 mm / 9x8.3x28.3 in
(with sunshield)
-Internal dimensions: 116x116x562 mm / 4.5x4.5x22.1 in
(max. lenght)
116x116x477 mm / 4.5x4.5x18.7 in
(with circuit, Fig. 4)
116x116x473 mm / 4.5x4.5x18.6 in
(with circuit, Fig. 5)
-Weight: 13 Kg
-Material: Stainless steel AISI 316
-Weatherproof: IP67
Heater
-Power supply: 12V DC/24V AC, 20 W
110-240V AC, 40 W
-Temperature ON: < 15°C ± 3°C
< 59°F ± 5°F
-Temperature OFF: > 22°C ± 3°C
> 72°F ± 5°F
Brackets
Wall bracket
-Dimensions:
140x185x597 mm / 5.5x7.3x23.5 in
-Weight: 5,5 Kg
Wall mount, two degrees of freedom, load rating 55 Kg. See Fig. 10.
Angled adapter
-Dimensions:
295x180x165 mm / 11.6x7.1x6.5 in
-Weight: 2,3 Kg
This adapter, along with the bracket, allows you to fix the housing at an
angle. Load rating 50 kg. See Fig. 11.
Pole adapter
-Dimensions:
190x174x100 mm / 7.5x6.9x4 in
-Weight: 2,5 Kg
This adapter, along with the bracket, allows you to fix the housing onto
a pole. The size of the pole can be between Ø 110 and Ø 150 mm in
diameter. Load rating: 50 kg. See Fig. 12.
