10.10 Cable glands
CABLE GLANDS SELECTION TABLE
Zone - Gas Cable gland
type Certification Operating
temperature
Cable Cable glands
part code External
diameter
(mm) Diameter
under
armour
(mm)
IIC Zone 1 or
Zone 2
IIB or IIA Zone 1 Barrier IECEX / ATEX /
GOST -60 / +80°C
-76 / 176°F Not armored OCTEXB3/4C 13 - 20.2 -
Armored OCTEXBA3/4C 16.9 - 26 -
IIB or IIA Zone 2 With gasket IECEX / ATEX /
GOST -60 / +100°C
-76 / 212°F Not armored OCTEX3/4C 13 - 20.2 -
Armored OCTEXA3/4C 16.9 - 26 11.1 - 19.7
ATEX -20 / +80°C
-4 / 176°F Not armored OCTEX3/4 14 - 17 -
Armored OCTEXA3/4 18 - 23 14 - 17
Tab. 01
OSLIEX Internal slide complete with
heater for EXHC
OSLIEXD Internal slide complete with
heater for EXHD
10.9 Package
Unit Weight:
EXHC 15kg / 33lb
EXHD 24kg / 52.9lb
Package Weight:
EXHC 17.5kg / 38.6lb
EXHD 24kg / 52.9lb
Package Dimensions (BxHxL):
EXHC 61x32x31cm /
24x12.6x12.2in
EXHD 43x67x67cm /
16.9x26.3x26.3in
10.7 Compliance to
For each version, verify the existing certification:
IECEx (TUV Nord Certification), protocols IEC 60079-
0:2007, IEC 60079-1:2007, IEC 60079-31:2008
ATEX (TUV Nord Certification), directive 94/9/CE
GOST-R (NANIO CCVE Certification)
Chinese certification (CNEx certification)
10.8 Spare parts list
OEXGOM Gaskets for cable glands Ex
d 3/4" NPT IP66 ATEX not
armored
OEXVET Front flange complete with
glass for EXHC RAL7032
OEXDPV Front flange complete with
glass protection device for
EXHD RAL 7032
OEXMYLAR Mylar film replacement kit,
18m (59ft) 350 steps
