Devices to install inside the housing
Camera: Analogue or network camera
Camera equipped with lens with maximum total power:
20W
Maximum voltage: 240Vac (24Vac or 230Vac versions)
Usable volume for camera/lens: 2800cm
3
Minimum distance between the walls of the housing and
the camera/lens: 12mm
10.4 Accessories
EXHS000 Sunshield 650mm for EXHC
EXHS001 Sunshield 760mm for EXHD
OCTEX3/4C Cable gland with gasket EX
3/4" NPT unarmoured cable
IECEX-ATEX-GOST
OCTEXA3/4C Cable gland with gasket EX
3/4" NPT armoured cable
IECEX-ATEX-GOST
OCTEXB3/4C Barrier cable gland EX 3/4"
NPT, anarmoured cable
IECEX-ATEX-GOST
OCTEXBA3/4C Cable gland with gasket EX
3/4" NPT armoured cable
IECEX-ATEX-GOST
OCTEX3/4 Cable gland with gasket EX
3/4" NPT unarmoured cable
ATEX
OCTEXA3/4 Cable gland with gasket EX
3/4" NPT armoured cable
ATEX
OEXPLUG3/4 Plug EX 3/4" NPT IECEX-
ATEX-GOST
10.5 Related products
EXWBJ000 Wall bracket and ball joint
for EXH RAL7032
EXWBJ00R Wall bracket and ball joint
for EXH RAL7001
EXBJ000 Ball joint for EXH RAL7032
EXBJ00R Ball joint for EXH RAL7001
10.6 Environment
Operating temperature with heater: -20°C / +50°C
Operating temperature with reinforced heater:
-40°C / +50°C
Always refer to the temperature in the marking
10 Technical data
10.1 General
Non-corrosive die-cast aluminium (anticorodal)
Bicomponent polyurethane enamel with orange peel
effect, RAL7032
Special painting, blue colour RAL7001. Resistant to stress
cracking, adverse weather conditions, detergents, salt-
spray and typical airborne pollutants
10.2 Mechanical
2 holes for cable glands 3/4" NPT
External dimensions
EXHC Ø 210mmx427.5mm
(8.2x16.8in)
EXHD Ø 250x573.5mm (9.8x 22.6in)
Internal dimensions
EXHC Ø 180x380mm (7x14.9in)
EXHD Ø 180x460mm (7x 18.1in)
Internal usable area
EXHC 100x100x280mm
(3.9x3.9x11in)
EXHD 100x100x280mm
(3.9x3.9x11in)
Glass window
EXHC Ø 114mm (4.5in)
EXHD 70x56mm (2.7x2.2in)
Device for the protection of the glass
Device for the protection of the glass Ø 250x140mm
Mylar film 80mm (3.1in) wide and 18m (59ft) length, 350
shifting steps, marks printed on the last 50cm (19in)
Wall mount
Load rating: 35kg (77lb)
Length: 455mm (17.9in)
Parapet mount
Load rating: 35kg (77lb)
10.3 Electrical
Heater Ton 15°C +/-4°C Toff 22°C +/-3°C
IN 24Vac, consumption 20W max
IN 230Vac, consumption 20W max (only for EXHC200)
Reinforced heater Ton 15°C +/-4°C Toff 22°C +/-3°C
IN 24Vac, consumption 20W max
3 resistors in the housing, consumption 60W max
Glass protection device
24Vac, consumption 2W max
