6.1.4 Connection of the power supply
line
Earth cable should be about 10mm longer
than the other two, so that it will not be
disconnected accidentally if pulled.
Connect the J1 power supply terminal to the electric
mains using suitable section cable (min. 1.5mm²).
Close the box, taking care to position the seals
correctly, and lock the cable glands.
The system is ready to be powered.
7 Configuration
The product has already been set in the factory for
optimal operation under a range of conditions, but
it can be adapted to suit the conditions where it will
actually be used.
Use trimmer P1 to adjust the intervention threshold
of the dusk sensor.
By rotating the trimmer clockwise, the night mode
changeover is anticipated (at a greater luminous
value). By rotating the trimmer anti-clockwise,
the night mode changeover is delayed (at a lower
luminous value).
We recommend making the adjustments under the
actual conditions in which the spots will be used.
The switching on of the red LED on the board stands
for the activation of the night-time mode.
8 Maintaining and cleaning
8.1 Maintaining
Maintenance must be carried out by
personnel trained to operate on electrical
circuits.
8.1.1 Fuses replacement
Use fuses with the following features:
T2A H 250V (F1), F8A L 250V (F2).
9 Disposal of waste
materials
This symbol mark and recycle system
are applied only to EU countries and not
applied to the countries in the other area of
the world.
Your product is designed and manufactured with
high quality materials and components which can be
recycled and reused.
This symbol means that electrical and electronic
equipment, at their end-of-life, should be disposed of
separately from your household waste.
Please dispose of this equipment at your local
Community waste collection or Recycling centre.
In the European Union there are separate collection
systems for used electrical and electronic products.
