11
DNX7230DAB/DNX5230DAB/DNX5230BT/DNX4230DAB/DNX4230BT
Number Name Motion
1
Disc insert
slot A slot to insert a disc media.
2
0 (Eject) • Ejects the disc.
• Pressing for 1 second ejects the disc forcibly.
3
fi (Reset) • If the unit or the connected unit fails to operate properly, the unit returns
to factory settings when this button is pressed (Instruction Manual
P.109).
• If the Security Indicator (SI) function is turned on, this indicator flashes
when the vehicle ignition is off (Instruction Manual P.80).
4
Release key Detaches the part of front panel.
5
MENU • Displays the Top Menu screen (Instruction Manual P.19).
• Pressing for 1 second turns the power off.
• When the power off, turns the power on.
6
NAV • Displays the navigation screen.
• Pressing for 1 second switches AV out sources.
7
∞, 5 • Adjusts volume.
8
TEL • Displays the Hands Free screen (Instruction Manual P.64).
• Pressing for 1 second displays the Voice Recognition screen. (Instruction
Manual P.72)
9
Input jack An input jack for external device.
10
microSD
card slot A slot to insert an SD card. The card is used for upgrading the map. For
how to upgrade the map, refer to the instruction manual of the navigation
system.
Also, you can play audio/visual file in the card.
