TPC-66 Series User Manual 56
Appendix B Fuse Specifications
B.1 Fuse Specifications
Rating: 250 VAC, 3.15A
Size: 5 x 20 mm
B.2 Fuse Replacement
Step 1: Remove the fuse cover
Step 2: Replace the damaged fuse with a new one
Step 3: Replace the fuse cover
Figure B.1: Fuse Replacement
Note The fuse is set to break if the input voltage
exceeds 33 VDC.
Warning Do NOT replace the fuse unless it is damaged.
Do NOT replace the fuse with a different rated fuse.
