TPC-66 Series User Manual
2
Chapter 1 General Information
1.1 Introduction
The TPC-66 series of touch panel computers consist of state-of-the-art
HMI (Human Machine Interfaces). The 5.7"/ 5.6" operator interface com-
bined with a RISC-based computing platform offers these key features:
• Bright Display:
The high-brightness LCD display provides a clear interface.
• Fanless:
By using a low power processor, the system does not have to rely on
fans, which often are unreliable, and attracts dust.
• Powerful Communication Capability:
The TPC-66 series provides a powerful I/O interface for easy
communication with other devices. The I/O interface includes serial
ports, RS-485 port, Ethernet and USB.
• Windows CE Support:
Advantech offers platform support for Windows CE. The optional
Windows CE operating system specifically for the TPC-66 is available
for Windows CE application program builders.
• JVM Support:
TPC-66 is powered by JVM that is compatible with Personal Java 1.2.
1.2 Specifications
1.2.1 System Kernel
• CPU: Intel XScale PXA 270 (CPU Clock 416 MHz)
• VGA: CPU Built-in
• DRAM: Built-in 64MB SDRAM
• Storage Memory: 64MB onboard NAND Flash
• Ethernet: SMSC9115 10/100Base-T Ethernet controller; IEEE 802.3u
protocol compatible
• Watchdog Timer: Intel XScale PXA watchdog timer; 2,5,10,15,30,40
second timeout period option
• CompactFlash: CompactFlash type I/II
