TPC-66 Series User Manual
4
1.3 LCD Specifications
1.4 Touchscreen Specifications
TPC-66SN
TPC-66T
Display Type
Color STN LCD
TFT LCD
Size (diagonal)
5.7”
5.6”
Maximum Resolution
320 x 240 (QVGA)
Maximum Colors
4096
256K
Pixel Pitch (W x H)
0.12 x 0.36 mm
Viewing Angle
100°
100°
Luminance (cd / m2)
400
500
Contrast Ratio
55
400
Operating Temperature 0 ~ 50° C (Ambient)
Control
Contrast Adjustable
N/A
Backlight
1 CCFL
Backlight MTBF
75,000 hours
30,000 hours
Touch Type
Resistive
Base Glass Construction
Tempered Glass
Resolution
Continuous
Light Transmission
75% typical
Controller
DMC9000
Power Rating
5 VDC
Software Driver
Windows CE (embedded)
Durability
10 million times with a 8 mm diame-
ter silicone rubber finger
Note
There is no pointer/cursor shown using the touch
screen. The cursor only appears when closing or
minimizing the window.
