General nozzle table
General nozzle table for town gas
The nozzles for town gas are not supplied with the appliance.
You can order the nozzles from the after-sales service.
Nominal operating pressure
The nominal operating pressure of your appliance is:
■
for natural gas - NG (G20) 20 mbar / 2.0 kPa.
■
for liquefied gas - LPG (G30) 30 mbar / 3.0 kPa.
■
for liquefied gas - LPG (G31) 37 mbar / 3.7 kPa.
Nominal operating pressure for town gas
The nominal operating pressure of your appliance is:
■
for town gas (G110) 8 mbar / 0.8 kPa;
■
for town gas (G120) 8 mbar / 0.8 kPa;
Your appliance must be operated at these pressure values. All
information on the rating plate refers to these pressure values.
The manufacturer does not accept any liability for operability,
power of the appliance or for other risks if the appliance is
operated at pressure values other than those values specified
for the appliance.
Note: If you are operating the appliance with liquefied gas, use
a gas pressure regulator. The pressure regulator must be
connected and maintained by a licensed technician.
Positioning and levelling
Positioning the appliance
When installing the appliance, make sure that there is enough
space in the final installation location to pull the appliance
forwards for cleaning and maintenance work.
The ground underneath must be hard and firm. The wall
immediately behind the appliance must be made from non-
flammable material, e.g. tiles.
If you need to move the appliance in order to position it, make
sure that the adjustable feet are fully screwed in.
Adjusting the appliance - Fig. 10
Turn the adjustable feet to level the appliance.
Note: Only level the appliance once all other work has been
completed.
Type of gas mbar kPa Nozzle Type of burner Power
W Power
min. (W) Max. consumption
Number Bypass G20 G30 G31
Natural gas -
NG
G20
20 2.0 115 (Y) Gap High output burner 3000 800 283 l/h
97 (Z) Gap Standard burner 1800 500 167 l/h
72 (X) Gap Economy burner 1000 400 97 l/h
135 (s) Gap Wok burner 3900 1600 359 l/h
Liquefied gas -
LPG
Butane
Propane
G30/G31
28 -
30/37 2.8 -
3.0/3.7 85 0.45 High output burner 3000 800 218 g/h 214 g/h
65 0.33 Standard burner 1800 500 131 g/h 129 g/h
50 0.30 Economy burner 1000 400 73 g/h 71 g/h
100 0.63 Wok burner 3900 1600 284 g/h 279 g/h
Type of gas mbar kPa Nozzle Type of burner Power
(W) Power
min. (W) Consumption max.
Number Bypass G110 G120
Town gas
G110 8 0.8 260 Gap High output burner 3000 800 648 l/h
185 Gap Standard burner 1750 500 384 l/h
145 Gap Economy burner 1000 400 219 l/h
340 Gap Wok burner 3700 1400 833 l/h
Town gas
G120 8 0.8 240 Gap High output burner 3000 800 582 l/h
175 Gap Standard burner 1800 500 354 l/h
135 Gap Economy burner 1000 400 201 l/h
315 Gap Wok burner 3900 1400 764 l/h
