26
|
KDV-MP5343U/ KDV-MP5443U/ KDV-MP4343/ KDV-MP4443
Preset position “PRESET”
Adjustment Item
Display
Not compensating.
“ALL”
Front-Left seat
“F-LEFT”
Adjustment Item
Display
Front-Right seat
“F-RIGHT”
Front seat
“F-ALL”
Manual position “MANUAL”
Adjustment Item
Display
Front Left speaker
“F-LEFT”
Front Right speaker
“F-RIGHT”
Rear Left speaker
“R-LEFT”
Rear Right speaker
“R-RIGHT”
Adjustment Item
Display
Subwoofer Left
“SW-LEFT”
Subwoofer Right
“SW-RIGHT”
Initialize the setting
values.
“INITIAL”
1
Enter Preset position setting mode
Press [
]
1 sec.
, and select “DSP”
>
“CONTROL”
>
“POSITION”
>
“PRESET”.
Press the [AUD] knob.
• For how to select Function Control items, refer to
2
Select the seat you want to compensate
Turn the [AUD] knob and push the center when
the desired item is displayed.
3
Exit Preset position setting mode
Press the [
] button.
You can fine-adjust your listening position.
1
Enter Manual position adjust mode
Press [
]
1 sec.
, and select “DSP”
>
“CONTROL”
>
“POSITION”
>
“MANUAL”.
Press the [AUD] knob.
2
Select the speaker you want to set
Turn the [AUD] knob and push the center.
Selecting “INITIAL” initializes the Manual position
✍
adjustment.
3
Set the value
Turn the [AUD] knob and push the center when
the desired value is displayed.
Adjust between 0 and 170 cm.
4
Exit Manual position adjust mode
Press the [
] button twice.
⁄
• About the position setting Alignment) Setting> (page 28). • When using the Subwoofer Left and Subwoofer Right as a single sub woofer, set the left side and right side to the Manual Equalizer Control You can adjust following Equalizer Control items; Adjustment Item Range Band level “BAND#” > “GAIN” -9 – 0 – +9 Bass Effect* “BAND1” > “EFFECT” “OFF”/ “ON” • *Can be only set for “BAND1”. 1 Enter Manual Equalizer Control mode Press [ ] 1 sec. , and select “DSP” > “CONTROL” > “EQ” > “MANUAL”. Press the [AUD] knob. • For how to select Function Control items, refer to 2 Select the band you want to set Turn the [AUD] knob and push the center. 3 Select the item you want to set Turn the [AUD] knob and push the center. 4 Set the value Turn the [AUD] knob and push the center when 5 Exit Manual Equalizer Control mode Press the [ ] button twice. ⁄ • When “iPod” is selected in the section select> (page 25), Manual Equalizer Control is disabled. • You can select for each source. Select the iPod Equalizer curve 1. Enter iPod Equalizer mode Press the [AUD] knob. 2. Select the iPod Equalizer curve Turn the [AUD] knob and push the center when 3 Exit Preset Equalizer mode. Press the [ ] button. ⁄ • You can select for each source. Position Control According to the listening position, select the Audio Adjustments B64-4430-00_00_M_English.indd 26 B64-4430-00_00_M_English.indd 26 09.2.13 10:19:19 AM 09.2.13 10:19:19 AM
First, set the using environment with
same value.
“BAND1” – “BAND5”
the desired item is displayed.
the desired item is displayed.
position from the following settings so that the
normal position of the sound environment can
be compensated in accordance with the selected
position;
