Communication Formats
• Ademco Contact ID
• 4+2 Standard
• SIA
NOTE: Ademco Contact ID must be used for independent zone
reporting.
Type Mode Feature
Ademco Contact ID format - only Use Type Mode to identify
reports to Central Station as:
• Fire Alarm • Burglary
• Supervisory • 24 hour Non-Burglary
• Pull Station • High Temperature
• Heat Detector • Low Temperature
• Waterflow • Low Water Pressure
• Duct Detector • Low Water Level
• Flame Sensor • Pump Failure
• Smoke Zone
Electrical Specifications
Standby current: 40 mA.
Current while communicating: 75 mA.
Maximum current while communicating and with open collector
output activated
: 100 mA.
Voltage: Regulated 24 volts. Range: 21.2 to 28.2 volts.
Agency Listings and Approvals
In some cases, certain modules may not be listed by certain
approval agencies, or listing may be in process. Consult factory
for latest listing status.
• UL/ULC Listed: S635
• FM Approved
• CSFM: 7165-0028:0243 (NFS2-640/320), 7165-0028:0224
(NFS2-3030)
• FDNY: COA#6085, COA#6098
Ordering Information
UDACT-2: Universal Digital Alarm Communicator Transmitter.
Includes operating and programming instructions, and mounting
hardware.
MCBL-7: DACT phone cord, 7 ft (2.13 m) long (two required).
ABS-8RB: Metal enclosure for externally mounting UDACT-2 up
to 6,000 ft./1828.8 m from host FACP. 9.94" H x 4.63" W x 2.50"
D (cm: 25.248 H x 11.760 W x 6.350 D).
UBS-1B: Metal enclosure with solid door, Black.
UBS-1BR: Metal enclosure with solid door, Red.
R-10E: SPDT Form-C relay. Contacts rated for 10 A @ 115 VAC.
Connects to open collector relay driver.
R-20E: DPDT Two Form-C relays. Contacts rated for 10A @ 115
VAC. Connects to open collector relay driver.
FBD-1: Ferrite bead kit. Use for remote mounting only.
UL Listed Receivers
The chart below shows UL listed receivers compatible with the
UDACT-2. A check in the protocol column indicates the receiver
supports that protocol.
(1) With 685-8 Line Card with Rev 4.4d software
(2) With 124060V206B and 124063 Line Card Rev B
(3) With version V2.4 Receiver & 126047 Line Card Rev G
(4) With 124077V2.00 Receiver &126047 Line Card Rev M
(5) With software V3.9
(6) With V.7301 Receiver S/W
(7) With 01.01.03 Receiver S/W & Line Card 01.01.03
(8) With software V1.86
(9) With sotware V1.72
(10) With DSP4016 and V1.6 Line Card
Receiver
4+2
Standard
1800/2300
Ademco
Contact
ID SIA
Ademco 685 (1)  
Ademco MX8000 (2)   
Silent Knight 9500 (3)   
Silent Knight 9800 (4)   
FBI CP220FB (5)   
Osborne Hoffman 2000E (6)  
Radionics 6600 (7)  
SurGard MLR2 (8)  
SurGard System III (9)  
SurGard MLR-2000 (10) 
