Page 2 of 2 — dn-60323:c1 • 11/9/11

System Sensor® is a registered trademark of Honeywell International Inc.

of this document is strictly prohibited.

This document is not intended to be used for installation purposes.

We try to keep our product information up-to-date and accurate.

We cannot cover all specific applications or anticipate all requirements.

All specifications are subject to change without notice.

For more information, contact Notifier. Phone: (203) 484-7161, FAX: (203) 484-7118.

www.notifier.com

Made in the U.S. A.

Candela Derating

NOTE: For K series products used at low temperatures, listed can-
dela ratings must be reduced in accordance with this table.

Architectural/Engineering Specifications

GENERAL

SpectrAlert Advance outdoor speaker and speaker strobes shall

mount to a weatherproof back box. A universal mounting plate

shall be used for mounting ceiling and wall products. The notifi-

cation appliance circuit and amplifier wiring shall terminate at

the universal mounting plate. Also, SpectrAlert Advance speaker

strobes, when used with the Sync•Circuit™ Module accessory,

shall be powered from a non-coded notification appliance circuit

output and shall operate on a nominal 12 or 24 volts. When

used with the Sync•Circuit Module, 12-volt rated notification

appliance circuit outputs shall operate between 9 and 17.5 volts;

24-volt rated notification appliance circuit outputs shall operate

between 17 and 33 volts. Outdoor SpectrAlert Advance prod-

ucts shall operate between –40°F and 151°F from a regulated

DC, or full-wave rectified, unfiltered power supply.

SPEAKER

The Speaker shall be a System Sensor SpectrAlert Advance

Model ______ dual voltage transformer speaker capable of

operating at 25.0 or 70.7 nominal Vrms. It shall be listed to UL/

ULC Standard S4048 for outdoor fire protective signaling sys-

tems. It shall have a frequency range of 400 to 4000 Hz and

shall have an operating temperature from –40°F to 150.8°F. It

shall have power taps and wattage settings which are selected

by rotary switches. The speaker must be installed with its weath-

erproof backbox in order to remain outdoor approved per UL/

ULC listing S4048. The speaker shall be suitable for use in air

handling spaces, as well as wet environments.

SPEAKER STROBE COMBINATION

The Speaker Strobe shall be a System Sensor Model _____

listed to UL/ULC 1638 and UL/ULC 1480 and be approved for

fire protective signaling systems. It shall be capable of operating

at 25.0 or 70.7 nominal Vrms, and shall have a frequency range

of 400 to 4000 Hz. It shall have power taps that are selected by

rotary switch. The strobe shall consist of a xenon flash tube with

associated lens/reflector system and operate on either 12V or

24V. The strobe shall also feature selectable candela output,

providing options for 15 or 15/75 candela when operating on

12V and 15, 15/75, 30, 75, 110, 115, 135, 150, 177 or 185 when

operating on 24V. The strobe shall comply with the Americans

with Disabilities Act requirement for visible signaling appliances,

flashing at 1 Hz over the strobe’s entire operating voltage range.

The speaker strobe must be installed with its weatherproof back

box in order to remain outdoor approved per UL/ULC. The

speaker strobe shall be suitable for use in wet environments.

Product Line Information

NOTE: “A” suffix indicates ULC-Listed model.
NOTE: All outdoor models (“K(A)” suffix), include weatherproof
backbox.
NOTE: Add “R” to outdoor models for weatherproof replacement
device (no backbox included).

SPWK(A): Wall mount outdoor speaker; white.
SPRK(A): Wall mount outdoor speaker; red.
SPSWK: Wall mount outdoor speaker strobe, selectable can-

dela (15, 15/75, 30, 75, 95, 110, 115); white.
SPSRK: Wall mount outdoor speaker strobe, selectable can-

dela (15, 15/75, 30, 75, 95, 110, 115); red.
SPCWK: Ceiling mount outdoor speaker; white.
SPSCWK: Ceiling mount outdoor speaker strobe, selectable

candela (15, 15/75, 30, 50, 75, 95, 110, 115); white.
SPSCWHK: Ceiling mount outdoor speaker strobe, selectable

candela, high cd (135, 150, 177, 185); white.

ACCESSORIES

MWBB(A): Wall, metal weatherproof backbox; red.
MWBBW(A): Wall, metal weatherproof backbox; white.
MWBBCW(A): Ceiling, metal weatherproof backbox; white.
WTP-SP: Flush mount weatherproof plate for use with speak-

ers/speaker strobes, red.
WTP-SPW: Flush mount weatherproof plate for use with speak-

ers/speaker strobes, white.

Sound Output
UL Reverberant (dBA @ 10ft)

½W ¼W

Outdoor Speaker

Outdoor Speaker/Speaker Strobe

UL Maximum Strobe Current Draw (mA RMS)

Candela

8 to 17.5 Volts

16 to 33 Volts

FWR

Standard

Candela

Range

123

128

15/75

142

148

158

153

181

176

110

202

195

115

210

205

High

Candela

Range

135

228

207

150

246

220

177

281

251

185

286

258

Strobe Output (cd)

Listed Candela

Candela Rating at -40°F

Do not use below 32°F

15/75

30
75

110

115

135

150

177

185
