General Specifi cations
Standard Specifications
Operating Voltage Range
10 to 32 V
DC
Power Consumption
Analog:
Nom 31 mA / 0.74 W
(at 24 V
DC
)
Max 65 mA / 1.56 W
Relay:
De-energized - Nom 39 mA / 0.94 W
Max 73 mA / 1.75 W
Energized - Nom 53 mA / 1.22 W
Max 86 mA / 2.06 W
Digital:
Nom 31 mA / 0.74 W
Max 65 mA / 1.56 W
Power Consumption
Analog:
Nom 46 mA / 0.55 W
(at 12 V
DC
)
Max 114 mA / 1.37 W
Relay:
De-energized - Nom 66 mA / 0.79 W
Max 138 mA / 1.66 W
Energized - Nom 93 mA / 1.12 W
Max 165 mA / 1.98 W
Digital:
Nom 46 mA / 0.55 W
Max 114 mA / 1.37 W
Temperature Range
Certified:
-40°C to +75°C (-40°F to +167°F)
Operational: -50°C to +85°C (-58°F to +185°F)
Field of View
90° vertical / 90° horizontal
Spectral Range
Wavelengths between 2.5 – 5.5 microns
Time Delay
Dip switch selectable to 0, 3, 5, 7 seconds
Sensitivity Settings
Two adjustable settings via DIP switch (high / low)
Typical Response Time <5
seconds
Enclosure Material
Yellow powdercoat with clear anodizing, copper-free aluminium (optional stainless steel), factory sealed housing
Humidity Range
0 to 95% RH, non-condensing
Weight (with swivel)
2.1 kg / 4.5 lb.
Stainless steel option: 3.4 kg / 7.5 lb.
Outputs
Analog:
Digitally stepped analog output 0 to 20 mA into a maximum loop impedance of 800 Ohms
at
32
V
DC
or 150 Ohms at 10.5 V
DC
. Isolated / non-isolated loop supply.
Relay:
Normally open/normally closed Form C contacts rated 5 Amps at 30 Vdc 125 V
AC
Selectable energized / de-energized fire relay. Fault relay fixed as energized. Both fire and fault
relays fixed as non-latching and cannot be modified.
Digital:
RS-485 RTU Modbus protocol
Certifications/Approvals
CSA - Class I, Division 1, Groups A (Canada only), B, C and D - Temperature code T5 - CANADA: Class 1, Zone 1, Ex d IIB + H2 T5
ANSI-UL/ISA - Class I, Division 1, Groups B, C and D - Temperature code T5 - UNITED STATES: Class 1, Zone 1, AEx d IIB + H2 T5
ATEX - EEx d II B+H2 T5
GOST-R - 1Ex d II BT5/H2
INMETRO - BR-Ex d II B+H2 T5
Factory Mutual (FM) 3260 Performance Certification
SIL 2 Rated NEMA Type 4X
IP66 - Enclosure ratings
Warranty
7 years (see website for details)
