©2014 by Honeywell International Inc. All rights reserved. Unauthorized use
of this document is strictly prohibited.
Page 2 of 2 — Canadian DN-60790:A • 2/27/14
This document is not intended to be used for
installation purposes. We try to keep our
product information up-to-date and accurate.
We cannot cover all specific applications or
anticipate all requirements. All specifications are
subject to change without notice.
For more information, contact Notifier.
(888) 289-1114
10 Whitmore Road
Woodbridge, Ontario LZL 7Z4
www.notifier.com
F ILTRATION :
Serviceable filter.
External filter optional.
F LOW M ONITORING AND R EPORTING :
High and Low programmable flow limits.
A SPIRATOR :
Control: 10 programmable speeds.
Pressure: 250 Pa.
R ELAY OUTPUTS :
XAS-1-US: 1 fault relay output.
XAS-2-US: 2 fault relay outputs.
F IELD W IRING :
Screw Terminals
18 to 10 AWG (0.9 to 5.5 sq. mm) solid.
20 to 12 AWG (0.6 to 3.5 sq. mm) stranded.
Ordering information
XAS-1-US: Air-sampling Smoke Detector with single zone.
XAS-2-US Air-sampling Smoke Detector with dual zone.
FSA-851A: Addressable photo detector; with FlashScan®,
compatible with XAS-1-US and XAS-2-US.
B501A: Flangeless mounting base.
02-FL53: Filter element (Pkg of 10).
LF42241: Single Zone Duct Installation Kit.
LF42243: Dual Zone Duct Installation Kit.
LF42246: 50' Flexible Dual Tube.
LF42247: 25' Flexible Dual Tube.
LF42249: 50' Flexible Single Tube.
LF42250: 25' Flexible Single Tube.
LF42285: 18" Probe Kit (one - 18" sample & one - 8" exhaust).
LF42286: 36" Probe Kit (one - 36" sample & one - 8" exhaust).
LF42287: 60" Probe Kit (one - 60" sample & one - 8" exhaust).
LF42288: 18" Probe Kit (two -18" sample & one - 8" exhaust).
LF42289: 36" Probe Kit (two - 36" sample & one - 8" exhaust).
LF42290: 60" Probe Kit (two - 60" sample & one - 8" exhaust.)
LF42282: Single Zone water trap kit.
LF42283: Dual Zone water trap kit.
06-NF10: Baffles for Spot Detector and for the use with FSA-
851A. (Package of 10).
Listings and Approvals
These listings and approvals apply to the modules specified in
this document. In some cases, certain modules or applications
may not be listed by certain approval agencies, or listing may
be in process. Consult factory for latest listing status.
• ULC S24829.
