Page 2 of 2 — dn-7000:a2 • 06/17/10
NOTIFIER® is a registered trademark of Honeywell International Inc.
©2010 by Honeywell International Inc. All rights reserved. Unauthorized use
of this document is strictly prohibited.
This document is not intended to be used for installation purposes.
We try to keep our product information up-to-date and accurate.
We cannot cover all specific applications or anticipate all requirements.
All specifications are subject to change without notice.
For more information, contact Notifier. Phone: (203) 484-7161, FAX: (203) 484-7118.
www.notifier.com
Made in the U.S. A.
Contact Ratings
Product Line Information
NC-100: Intelligent addressable control module.
NC-100(A): Intelligent addressable control module, ULC listed
version.
SMB500: Optional surface-mount backbox.
CB500: Optional control module barrier, required by UL for
separating power-limited and non-power-limited wiring in the
same junction box as NC-100(A).
NOTE: For installation instructions, see document I56-2592-001
and refer to the SLC Wiring Manual, document 52304. The NC-
100R(A) relay module, previously on this data sheet, is now on
DN-60383.
Current
Rating
Maximum
Voltage
Load
Description Application
3 A 30 VDC Resistive Non-Coded
2 A 30 VDC Resistive Coded
.9 A 110 VDC Resistive Non-Coded
.9 A 125 VDC Resistive Non-Coded
.5 A 30 VDC
Inductive
(L/R=5ms)
Coded
1 A 30 VDC
Inductive
(L/R=2ms)
Coded
.3 A 125 VAC
Inductive
(PF=0.35)
Non-Coded
1.5 A 25 VAC
Inductive
(PF=0.35)
Non-Coded
.7 A 70.7 VAC
Inductive
(PF=0.35)
Non-Coded
2 A 25 VAC
Inductive
(PF=0.35)
Non-Coded
