Specifications
Normal operating voltage: 15 to 32 VDC.
Maximum current draw: 7.5 mA (LED on).
Average operating current: 7.5 mA group poll (FlashScan®
mode) with LED flashing.
External supply voltage (between Terminals T3 and T4):
maximum 28 VDC.
EOL resistance: 3.9K ohms.
Temperature range: 32°F to 120°F (0°C to 49°C).
Humidity range: 10% to 93% non-condensing.
Dimensions: 4.5" (11.43 cm) high x 4" (10.16 cm) wide x
1.25" (3.175 cm) deep. Mounts to a 4" (10.16 cm) square x
2.125" (5.398 cm) deep box.
Weight: 6.3 oz.
SOFTWARE COMPATIBILITY
• NFS-640 - As of Version 3.1.3
• NFS2-640 - As of version 10.0
• NFS-3030 - As of Version 2.2.9
• NFS2-3030 - As of version 10.0
• LCM - As of Version 2.3.7
Product Line Information
FTM-1: Intelligent Addressable Firephone Control Module,
3.9K ohm End-of-Line Resistor included.
FTM-1A: Same as FTM-1 with ULC listing.
SMB500: Optional Surface-Mount Electrical Backbox.
CB500: Control Module Barrier — required by UL for separat-
ing power-limited and non-power-limited wiring in the same
junction box as FTM-1.
