Maximum NAC Line Loss: 4 VDC.
External supply voltage (between Terminals T10 and

T11): Maximum (NAC): Regulated 24 VDC; Maximum

(Speakers): 70.7 V RMS, 50W.
Drain on external supply: 1.7 mA maximum using 24 VDC

supply; 2.2 mA Maximum using 80 VRMS supply.
Max NAC Current Ratings: For class B wiring system, the

current rating is 3A; For class A wiring system, the current rat-

ing is 2A.
Temperature range: 32°F to 120°F (0°C to 49°C).
Humidity range: 10% to 93% non-condensing.
Dimensions: 4.5" (114.3 mm) high x 4" (101.6 mm) wide x

1.25" (31.75 mm) deep. Mounts to a 4" (101.6 mm) square x

2.125" (53.975 mm) deep box.
Accessories: SMB500 Electrical Box; CB500 Barrier

Specifications for FRM-1(A)

Normal operating voltage: 15 to 32 VDC.
Maximum current draw: 6.5 mA (LED on).
Average operating current: 230 μA direct poll; 255 μA group

poll.
EOL resistance: not used.
Temperature range: 32°F to 120°F (0°C to 49°C).
Humidity range: 10% to 93% non-condensing.
Dimensions: 4.5" (114.3 mm) high x 4" (101.6 mm) wide x

1.25" (31.75 mm) deep. Mounts to a 4" (101.6 mm) square x

2.125" (53.975 mm) deep box.
Accessories: SMB500 Electrical Box; CB500 Barrier

Agency Listings and Approvals

In some cases, certain modules may not be listed by certain

approval agencies, or listing may be in process. Consult fac-

tory for latest listing status.

UL: S635

ULC: S3705 (A version only)

• FM Approved

CSFM: 7300-0028:0219

MEA: 14-00-E

FDNY: COA #6067, #6065

Contact Ratings for FRM-1(A)

NOTE: Maximum (Speakers): 70.7 V RMS, 50 W

Product Line Information

NOTE: “A” suffix indicates ULC Listed model.

FCM-1(A): Intelligent Addressable Control Module.
FRM-1(A): Intelligent Addressable Relay Module.
A2143-20: Capacitor, required for Class A (Style Z) operation

of speakers.
SMB500: Optional Surface-Mount Backbox.
CB500: Control Module Barrier — required by UL for separat-

ing power-limited and non-power limited wiring in the same

junction box as FCM-1(A).

NOTE: For installation instructions, see the following documents:

FCM-1(A) Installation document I56-1169.

FRM-1(A) Installation document I56-3502.

Notifier SLC Wiring Manual, document 51253.

Current

Rating

Maximum

Voltage

Load

Description Application

3 A

30 VDC

Resistive

Non-Coded

2 A

30 VDC

Resistive

Coded

.9 A

110 VDC

Resistive

Non-Coded

.9 A

125 VDC

Resistive

Non-Coded

.5 A

30 VDC

Inductive
(L/R=5ms)

Coded

1 A

30 VDC

Inductive
(L/R=2ms)

Coded

.3 A

125 VAC

Inductive
(PF=0.35)

Non-Coded

1.5 A

25 VAC

Inductive
(PF=0.35)

Non-Coded

.7 A

70.7 VAC

Inductive
(PF=0.35)

Non-Coded

2 A

25 VAC

Inductive
(PF=0.35)

Non-Coded
