SPECIFICATIONS
MAIN AUDIO PAT H
Connector:
1/4Ó Unbalanced Input/Output
Input Impedance:
77kOhm
Output Impedance:
1kOhm
SNR:
94dB (A-Weighted)
THD:
<0.012%
Max Input:
18.2 dBu
Frequency Response: +0/-0.7dB (20Hz to 20kHz)
Gain:
21dB to negative infinity
EFFECTS LOOP PAT H
Connector:
1/4Ó Unbalanced Input/Output
Input Impedance:
77kOhm
Output Impedance:
1kOhm
SNR:
94dB (A-Weighted)
THD:
<0.013%
Max Input:
18.2 dBu
Frequency Response: +0/-0.6dB (20Hz to 20kHz)
Gain:
0dB
INSTRUMENT PAT H
Connector:
1/4Ó Unbalanced Input
Input Impedance:
500kOhm
SNR:
94dB (A-Weighted)
THD:
<0.014%
Max Input:
18.2 dBu
Frequency Response: +0/-0.5dB (20Hz to 20kHz)
Gain:
21dB to negative infinity
PHONO PAT H
Connector:
RCA (phono/line) Input
Input Impedance:
47kOhm (phono/line)
SNR:
94dB (A-Weighted)
THD:
<0.28% (phono), <0.014% (line)
Max Input:
-19 dBu (phono), 18.2 dBu (line)
Frequency Response: +2.5/-0.2dB (20Hz to 20kHz phono)
+0/-0.75dB (20Hz to 20kHz line)
Gain:
36dB @ 1kHz
POWER CONSUMPTION 15W
USE ONLY WITH ELECTRIX
POWER SUPPLY MODEL TFR0035
Vo l t a g e
100-240 V
Fr e q u e n c y
47/63Hz
