D I S P L AYED MESS A G E S
For those of you who hate reading manuals, weÕve matched LCD displays to brief descriptions so you can quickly flip
to what you want to know.
Power Up
On power up. Software Version. Detects CFC.
Loop Location
CFC Memory
Internal Memory
Multiply Loop
Press Multiply Loop and the loop is instantly doubled
in length. Press and hold Multiply Loop and use the
Tempo knob to dial in another multiple.
Tr i m L o o p
¥ The first press of Trim will put you into the Bars Trim mode. The
Loop knob will remove whole bars from the front of the track, the
Tempo knob removes bars from the end of the track.
¥ Press Trim again to go into Seconds Trim mode. In Seconds Trim
mode the display shows the start and end points of the loop in
min.sec.sec/100, which you can modify with the Loop and Tempo
knobs. These changes will affect your tempo, and the Bars and Beats
will be recalculated according to the rule: Seconds = Bars x Beats x
((Tempo/60)/Div). For example, in 3/4 time, the Beats value would be
3 and the Div would equal 4. 4/4 time the values would be Beat = 4,
Div = 4.
U n d o
Press Erase/UNDO, and the display reads " " for a second.
Press Erase/UNDO, a second time and the display reads " ".
E r a s e
Press and hold the Erase/UNDO button to put the unit into erase
mode. The display shows four " "s and flashes all four Track Select but-
tons, the Stop button and the Erase button. Only the Erase button
enacts the erase. All other button presses cancel the erase. Track Select
buttons are used to select/deselect tracks to be erased. If all tracks are
erased then the loop becomes EMPTY. If the Erase button is pressed then
the tracks are erased and the display shows the progress and
finishes with "
".
English... 40
REFERENCE
