12/10/07 Model LE13A Text 19
6. Turn the auto-manual selector to AUTO and press the blade drive button. The
blade will run and the automatic operation will begin.
7. After the required number of cuts have been completed, the saw blade will stop
in the lower position and all machine operations will stop.
NOTE:
i. During automatic operation, shifting the auto-manual selector to
MANUAL will cause the saw blade to stop in the lower position,
after completion of the cutting operation on which the selector was
shifted.
NOTE:
If the machine does not start be sure the vise switch (item 8 in the control panel
description) is turned to the left.
4.7 How to install bundle attachments
How to use the bundle cutting attachments
WARINING!!!!!
Never install the bundle attachments while the machine is in
operation. This machine electricity must be locked out before
installing bundle attachments.
WARNING!!!!!
Keep fingers clear of vise, personal injury could occur.
This multi-vise is used when bundle cutting is performed. To perform bundle cutting,
proceed as follows:
1. Install the stud bolts on the front and rear vises and position the multi-vise on
the front and rear vises.
2. Connect the multi-vise hoses to their quick connectors at the front and rear vise
cylinders.
3. Attach the bundle cutting fence to the work tray. The fence is designed to
prevent the cut pieces from spreading out across the work tray. Adjust the width
of the fence so that it equals the width of the bundle.
