Vi-D5000 IR Dome
Videoswitch Page 1 VD601A.DOC
1 Overview
1.1 Model Specific
Vi-D5030 Vi-D5036
Analogue Zoom x30 x36
Digital Zoom x12 x12
TVL 800 540
BLC No Yes
WDR No Yes
Wiper Yes Yes
IR Range up to
150m 150m
Privacy No Yes
Tracking No No
1.2 Specification
Horizontal Rotation Speed 0.02°-280°/s
Tilt Rotation Speed 0.02°-160°/s
Horizontal Rotation Range 360°
Tilt Rotation Range 93°
Auto Flip Horizontal 180°, Vertical 90°
Auto control IR LED PWM
A-B Scan User programmable
A-B Scan Speed 1-9 speed setting available
360° Scan Speed 1-9 speed setting available
Dwell Preset 5-60s interval
Preset Points 220
Go to Preset Speed 200°/s
Guard Tours 4 groups
Guard Points Max.16 points, dwell time user selectable
Pattern Scan 4 patterns
Pattern Scan Record max.15 minutes, max.512 commands
Home Pos Time 1-60mins available
PWR on Action
Memory as power off/Pattern/360° scan/A-B
scan/Preset cruise/Preset 1-8/No action
Communication Protocol
Pelco-D, Pelco-P (BBV up-the-coax via PSU option
module)
Communication RS485 Bus
Baud Rate 1200/2400/4800/9600bps
Time Scheduling function 8 tasks
Operating Temperature Outdoor: -40°~ +60°
Operating humidity ≤95% Non Condensing
Heater & Blower Auto temperature control
Power AC/DC15-28V ≤3A
Lightning protection transient voltage 3000V
LED Angle of Illumination Ш20=8,Ш16=5
