Vi-D5000 IR Dome
Videoswitch Page 31 VD601A.DOC
5.4 Address Code Mapping Table
SW1 DIP Switch sets the dome address, which using binary encoded. The 8th is the top bits, and 1st is the
lowest bits. If a switch to ON that is a logical “1”. If a switch is OFF that is a logical “0”.
5.4.1 Dome address code mapping table for PELCO_D
Switch Settings
Address
SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8
0 OFF OFF OFF OFF OFF OFF OFF OFF
1 ON OFF OFF OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF OFF OFF
3 ON ON OFF OFF OFF OFF OFF OFF
4 OFF OFF ON OFF OFF OFF OFF OFF
5 ON OFF ON OFF OFF OFF OFF OFF
6 OFF ON ON OFF OFF OFF OFF OFF
7 ON ON ON OFF OFF OFF OFF OFF
8 OFF OFF OFF ON OFF OFF OFF OFF
9 ON OFF OFF ON OFF OFF OFF OFF
10 OFF ON OFF ON OFF OFF OFF OFF
11 ON ON OFF ON OFF OFF OFF OFF
12 OFF OFF ON ON OFF OFF OFF OFF
13 ON OFF ON ON OFF OFF OFF OFF
14 OFF ON ON ON OFF OFF OFF OFF
15 ON ON ON ON OFF OFF OFF OFF
16 OFF OFF OFF OFF ON OFF OFF OFF
17 ON OFF OFF OFF ON OFF OFF OFF
18 OFF ON OFF OFF ON OFF OFF OFF
19 ON ON OFF OFF ON OFF OFF OFF
20 OFF OFF ON OFF ON OFF OFF OFF
21 ON OFF ON OFF ON OFF OFF OFF
22 OFF ON ON OFF ON OFF OFF OFF
23 ON ON ON OFF ON OFF OFF OFF
24 OFF OFF OFF ON ON OFF OFF OFF
25 ON OFF OFF ON ON OFF OFF OFF
--- ---- ---- ---- ---- ---- ---- ---- ----
250 ON OFF ON OFF ON ON ON ON
251 ON ON OFF ON ON ON ON ON
252 OFF
OFF ON ON ON ON ON ON
253 ON OFF ON ON ON ON ON ON
254 OFF
ON ON ON ON ON ON ON
255 ON ON ON ON ON ON ON ON
