VDC Digital Recorder
Vdc601c.doc
6
2
Viewing Live Images
Press this key to enter
LIVE mode:
2.1
Viewing Full Screen Images
Select full screen views of different cameras by pressing the
NUMERIC keys:
2.2 Quad
Display
Select quad display by pressing the
QUAD key (live display only):
2.3
9-way Multi-Screen (VDC-9 only)
Select x9 Multi-Screen display by pressing the
MULTISCREEN key (live display only):
