High Country Tek ProValve 200 Series - Manual (Page 12)

021-PV200 Rev A PV200 Uses Manual 12
Copyright © High Country Tek, Inc. – 2013
PV200
Closed Loop Proportional Valve Controller
B MAXIMUM OUTPUT - Sets the maximum output current for coil B (Amps). The value in the brackets is the
present output current.
B OVERRIDE - Sets the output current for a digital reverse override command. No ramping takes place during
override operations. The value in the brackets is the present output current.
DITHER FREQ. - Set the PWM or dither frequency according to the valve specifications. This parameter is variable.
Options: 35, 41, 49, 61, 81, 122, 244, (Select OFF for 15.63KHz)
OUTPUT CURRENT - Displays the present output current. This parameter is a monitor type.
SUPPLY VOLTAGE - Displays the module’s power supply voltage. It is helpful for troubleshooting. This parameter
is a monitor type.
FAULT STATUS - The Fault LED displays solid red light for both coil open and short until cycling the power to clear
the fault. Moving command signal out of active range will not clear faults.
