PV200
Closed Loop Proportional Valve Controller
Parameter List
This table outlines PV200 parameters, the limits and units for each parameter.
Parameter Limits Units
PV200 Version #
Proportional gain 0.0 to 100.0 %
Integral time 0.0 to 2.5 Sec
Derivative gain 0.0 to 100.0 %
Target deadband 0.0 to 25.0 %
Invert target Yes/No NA
Target minimum 0.0 to 100.0 %
Target maximum 0.0 to 100.0 %
Position minimum 0.0 to 100.0 %
Position maximum 0.0 to 100.0 %
A Minimum output 0.0 to 2.50
*
A
A Maximum output 0.0 to 2.50
*
A
A Override 0.0 to 2.50
*
A
B Minimum output 0.0 to 2.50
*
A
B Maximum output 0.0 to 2.50
*
A
B Override 0.0 to 2.50
*
A
Dither frequency 35, 41, 49, 61, 81, 122, 244
(select OFF for PWM frequency 15.63KHz)
Hz
Output current A
Supply voltage Volts
Fault status Fault
*
0 to 500mA for –L version
