GENERAL SPECIFICATIONS
1. POWER: Derived from system backplane. (75 mA load on power input of
MASTER). Module may be hot-swapped (replaced while powered up).
2. LEDs:
STS - Status LED shows module condition.
ALM - Alarm LED is lit during any internal alarm condition.
3. MEMORY: Non-volatile memory retains all programmable parameters.
MASTER also stores the parameters in order to reprogram modules that are
replaced.
4. ISOLATION LEVEL: 1000 Vrms @ 50/60 Hz for 1 minute between signal
inputs and between any signal input and the CS Master power supply input.
5. COMMUNICATIONS: Provided by the CS Master
6. INPUTS:
Channels: 8
Effective Resolution: Full 16-bit
Sample Time: 100 msec
Common Mode Rejection: >100 dB, 50/60 Hz
Normal Mode Rejection: >70 dB, 50/60 Hz
Temperature Coefficient: 0.01%/°C
Step Response Time: One scan time (to within 99% of final value)
Types: T, E, J, K, R, S, B, N, C
Slope & Offset: Provides sensor error correction
Input Impedance: 20 M

Lead Resistance Effect: 0.25 μV/ 
Cold Junction Compensation: Less than ±1 °C typical (±1.5 °C max) over 0
to 50 °C ambient temperature
Resolution: 0.1°
7. TEMPERATURE INDICATION ACCURACY: ± (0.3% of span, +1 °C).
Includes NIST conformity, cold junction effect, A/D conversion errors,
temperature coefficient and linearization conformity at 23 °C after 20 minute
warm up.
8. PROBE BREAK RESPONSE: Upscale drive, Input Fault Alarm bit set high,
ALM LED illuminates.
9. CERTIFICATIONS AND COMPLIANCES:
SAFETY
IEC 61010-1, EN 61010-1: Safety requirements for electrical equipment
for measurement, control, and laboratory use, Part 1.
ELECTROMAGNETIC COMPATIBILITY
Emissions and Immunity to EN 61326: 2006: Electrical Equipment for
Measurement, Control and Laboratory use.
Immunity to Industrial Locations:
Electrostatic discharge
EN 61000-4-2 Criterion B
4kV contact discharge
8kV air discharge
Electromagnetic RF fields EN 61000-4-3 Criterion B 3
10V/m (80 MHz to 1 GHz)
3 V/m (1.4 GHz to 2 GHz)
1 V/m (2 GHz to 2.7 GHz)
Fast transients (burst) EN 61000-4-4 Criterion B
power 2kV
I/O signal 1kV
Surge EN 61000-4-5 Criterion B
power 1 kV L to L, 2 kV L to G
signal 1 kV
RF conducted interference EN 61000-4-6 Criterion A
3 Vrms
Emissions:
Emissions
EN55011 Class A
Notes:
1. Criterion A: Normal operation within specified limits.
2. Criterion B: Temporary loss of performance from which the unit self-
recovers.
3. The module’s analog input and/or output signals may deviate during
disturbance, but self-recover when disturbance is removed.
4. Power supplied from backplane via Master Module.
10. ENVIRONMENTAL CONDITIONS:
Operating Temperature Range: 0 to +50 °C
Storage Temperature Range: -40 to +85 °C
Operating and Storage Humidity: 85% max relative humidity, non-
condensing, from 0 to +50 °C
Vibration According to IEC 68-2-6: Operational 10 to 150 Hz, 0.075 mm
amplitude in X, Y, Z direction 1 g.
Shock According to IEC 68-2-27: Operational 25 g, 11 msec in 3 directions.
Altitude: Up to 2000 meters
11. CONSTRUCTION: Case body is burgundy high impact plastic. For indoor
use only. Installation Category II, Pollution Degree 2.
12. CONNECTIONS: Removable wire clamp screw terminal blocks
Wire Gage: 28-16 AWG terminal gage wire
Torque: 1.96-2.23 inch/lbs (0.22-0.25 N-m)
13. MOUNTING: Snaps on to standard DIN style top hat (T) profile mounting
rails according to EN50022 -35 x 7.5 and -35 x 15.
14. WEIGHT: 6 oz (170.1 g)
EMC INSTALLATION GUIDELINES
Although Red Lion Controls Products are designed with a high degree of
immunity to Electromagnetic Interference (EMI), proper installation and wiring
methods must be followed to ensure compatibility in each application. The type
of the electrical noise, source or coupling method into a unit may be different
for various installations. Cable length, routing, and shield termination are very
important and can mean the difference between a successful or troublesome
installation. Listed are some EMI guidelines for a successful installation in an
industrial environment.
1. A unit should be mounted in a metal enclosure, which is properly connected
to protective earth.
a. The mounting clip that connects to the DIN rail should have the DIN rail
connected to protective earth.
2. Use shielded (screened) cables for all Signal and Control inputs. The shield
(screen) pigtail connection should be made as short as possible. The
connection point for the shield depends somewhat upon the application.
Listed below are the recommended methods of connecting the shield, in order
of their effectiveness.
a. Connect the shield to earth ground (protective earth) at one end where the
unit is mounted.
b. Connect the shield to earth ground at both ends of the cable, usually when
the noise source frequency is over 1 MHz.
c. Connect the shield to common of the module and leave the other end of the
shield unconnected and insulated from earth ground.
3. Never run Signal or Control cables in the same conduit or raceway with AC
power lines, conductors, feeding motors, solenoids, SCR controls, and
heaters, etc. The cables should be run through metal conduit that is properly
grounded. This is especially useful in applications where cable runs are long
and portable two-way radios are used in close proximity or if the installation
is near a commercial radio transmitter. Also, Signal or Control cables within
an enclosure should be routed as far away as possible from contactors, control
relays, transformers, and other noisy components.
4. Long cable runs are more susceptible to EMI pickup than short cable runs.
Therefore, keep cable runs as short as possible.
5. In extremely high EMI environments, the use of external EMI suppression
devices such as Ferrite Suppression Cores for signal and control cables is
effective. The following EMI suppression devices (or equivalent) are
recommended:
Fair-Rite part number 0443167251 (RLC part number FCOR0000)
TDK part number ZCAT3035-1330A
Steward part number 28B2029-0A0
6. To protect relay contacts that control inductive loads and to minimize radiated
and conducted noise (EMI), some type of contact protection network is
normally installed across the load, the contacts or both. The most effective
location is across the load.
No Standard
No Standard
No Standard
No Standard
-10.00 to +56.00 mV
0 to +2315 °C
+32 to +4199 °F
Millivolt
C
W5/W6
(+) Orange
(-) Blue
(+) Orange
(-) Red
-200 to +1300 °C
-328 to +2372 °F
N
No Standard No Standard
+149 to +1820 °C
+300 to +3308 °F
B
(+) White
(-) Blue
No Standard
0 to +1768 °C
+32 to +3214 °F
S
(+) White
(-) Blue
No Standard
0 to +1768 °C
+32 to +3214 °F
R
(+) Brown
(-) Blue
(+) Yellow
(-) Red
-200 to +1350 °C
-328 to +2462 °F
K
(+) Yellow
(-) Blue
(+) White
(-) Red
-200 to +760 °C
-328 to +1400 °F
J
(+) Brown
(-) Blue
(+) Violet
(-) Red
-200 to +730 °C
-328 to +1346 °F
E
(+) White
(-) Blue
(+) Blue
(-) Red
-200 to +400 °C
-328 to +752 °F
T
BS 1843 ANSI
WIRE COLOR MEASUREMENT
RANGE
TYPE
2
