2
SPECIFICATIONS
1. POWER: 24 VDC ± 10%
400 mA min. (1 module)
3 Amps max. (16 modules)
Must use NEC Class 2 or Limited Power Source (LPS) rated power supply.
2. COMMUNICATIONS:
USB/PG Port: Adheres to USB specification 1.1. Device only using Type B
connection.
Serial Ports: Format and Baud Rates for each port are individually software
programmable up to 115,200 baud.
RS232/PG Port: RS232 port via RJ12
COMMS Ports: RS422/485 port via RJ45, and RS232 port via RJ12
DH485 TXEN: Transmit enable; open collector, V
OH
= 15 VDC,
V
OL
= 0.5 V @ 25 mA max.
Note: For additional information on the communications or signal common
and connections to earth ground please see the “Connecting to Earth
Ground” in the section “Installing and Powering the CSMSTRSX.”
Ethernet Port: 10 BASE-T / 100 BASE-TX
RJ45 jack is wired as a NIC (Network Interface Card).
3. LEDs:
STS – Status LED indicates condition of master.
TX/RX – Transmit/Receive LEDs show serial activity.
Ethernet – Link and activity LEDs.
4. MEMORY:
On-board User Memory: 4 Mbytes of non-volatile Flash memory.
On-board SDRAM: 2 Mbytes
5. ENVIRONMENTAL CONDITIONS:
Operating Temperature Range: 0 to 50 °C
Storage Temperature Range: -30 to +70 °C
Operating and Storage Humidity: 80% max relative humidity,
non-condensing, from 0 to 50 °C
Vibration According to IEC 68-2-6: 5 to 150 Hz, in X, Y, Z direction for 1.5
hours, 2 g’s.
Shock According to IEC 68-2-27: Operational 25 g's, 11 msec in 3 directions.
Altitude: Up to 2000 meters
6. CONSTRUCTION: Case body is burgundy high impact plastic and
stainless steel. For indoor use only. Installation Category II, Pollution
Degree 2.
7. POWER CONNECTION: Removable wire clamp screw terminal block.
Wire Gage Capacity: 24 AWG to 12 AWG
Torque: 4.45 to 5.34 in/lb (0.5 to 0.6 N-m)
8. MOUNTING: Snaps onto standard DIN style top hat (T) profile mounting
rails according to EN50022 -35 x 7.5 and -35 x 15.
9. CERTIFICATIONS AND COMPLIANCES:
SAFETY
UL Listed, File #E302106, UL508, CSA 22.2 No. 14-M05
LISTED by Und. Lab. Inc. to U.S. and Canadian safety standards
IEC 61010-1, EN 61010-1: Safety requirements for electrical equipment for
measurement, control, and laboratory use, Part 1.
ELECTROMAGNETIC COMPATIBILITY
Emissions and Immunity to EN 61326: 2006: Electrical Equipment for
Measurement, Control and Laboratory use.
Notes:
1. Criterion A: Normal operation within specified limits.
2. Criterion B: Temporary loss of performance from which the unit self-recovers.
3. The module’s with analog input and/or output signals may have their
signals deviate during disturbance but self-recover when the disturbance
is removed.
10. WEIGHT: 12.9oz (365.7g)
Immunity to Industrial Locations:
Electrostatic discharge
EN 61000-4-2 Criterion B
4 kV contact discharge
8 kV air discharge
Electromagnetic RF fields EN 61000-4-3 Criterion B 3
10 V/m
Fast transients (burst) EN 61000-4-4 Criterion B
power 2 kV
I/O signal connected to power
I/O signal
2 kV
1 kV
Surge EN 61000-4-5 Criterion B
signal
power
1kV
1kV L-L,2 kV L-G
RF conducted interference EN 61000-4-6 Criterion A
3 V/rms
Emissions:
Emissions
EN 55011 Class A
ORDERING INFORMATION
TYPE MODEL NO. DESCRIPTION PART NUMBER
Master Module CSMSTR 1
Modular Controller Master, Comms, Ethernet CSMSTRV2
Modular Controller Master with multiple protocol converter, data logger, web server with Virtual
HMI up to QVGA (320 x 240) size and expansion slot.
CSMSTRSX
Modular Controller Master with multiple protocol converter, data logger, web server with Virtual
HMI up to VGA (640 x 480) size and expansion slot with increased SDRAM.
CSMSTRGT
Communications
Cables (10 feet)
CBL
RS232 Programming Cable CBLPROG0
USB Cable CBLUSB00
Communications Cables 1 CBLxxxxx
Software SFCRM2 Crimson 2.0 2 , Modular Controller Manual, and Download Cable SFCRM2MC
Power Supply PSDR DIN Rail Mounted Power Supply PSDRxxxx
Accessories
G3CF CompactFlash Card 3 G3CFxxxx
Rail Stops (Qty 2) RSRSTP00
Replacement Base CSBASE00
Replacement Termination Plug CSTERM00
1 Visit www.redlion.net for a complete list of PID modules, data acquisition modules, communications drivers and cables.
The CSMSTRV2 was designed as a direct replacement for the original CSMSTRSE. This new model provides benefits such as support via Crimson ® 2.0 software
that allows configuration files to be uploaded. To save programming time, files originally created in Crimson 1.0 (.cdb files) may be imported into Crimson 2.0.
2 Use this part number to purchase Crimson on CD with a printed Modular Controller Manual, USB cable, and RS-232 cable. Otherwise, download free of charge from
www.redlion.net.
3 Industrial grade two million write cycles. SMART Modular Technologies model SG9CF (UL Listed Directory Category NWGQ).
