Rev. Oct, 2013

ronbow.com

INStALLAtION GUIDe

INStALLAtION SHeet

ACCESSORIES

MODEL: 688026

688118

688225

OvERjOhn CAbInEt

MATERIALS NEEDED:

PHILIP SCREWDRIVER
LEVELING TOOL

MATERIAL PROVIDED:

(6)WOOD SCREWS
(6)aNCHORS
(2)mOuNTING PLaTES

Figure 1.

STEP 1:

Determine the ideal location of your new

overjohn cabinet. Make sure the cabinet has enough
clearance from toilet and ceiling.

See Figure 1.

minimum to toilet

minimum to Ceiling

1”

1”

Figure 2.

STEP 2:

Measure distance between two mounting

brackets and transfer measurement to mounting
location.

See Figure 2.

Figure 3.

STEP 3:

Install mounting plates (2) to the wall with

provided hardware.
Use proper hollow wall anchors if necessary.

See Figure 3.

Figure 4.

STEP 4:

Install cabinet to wall. Insuring mounting

brackets catch mounting plates.

See Figure 4.
