Vaisala PTB200 User Manual
Page 4
PTB 200
3 (28)
Digital Barometers
SSD/Operating Manual
24th February 1993
PTB200-O0284-1.1
2
INSTALLATION
2.1
Mounting
The dimensions and recommended mounting positions of the PTB 200
barometers are shown in Figure 1.
27.5 (1.08)
120 (4.72)
65 (2.56)
Ø 6.5 (0.26)
104 (4.09)
139.5 (5.49)
145 (5.71)
133 (5.24)
120 (4.72)
Fig. 1
Dimensions and mounting of PTB 200 barometers
See Chapter 2.2 Grounding and 2.6 Pressure connection for further
information on electrical grounding and pressure connection
alternatives.
