Output Temperature Chart
‐ 50 ‐
│
Page
OUTPUT TEMPERATURE CHART
Output Temperature vs. GPM (Max. 9.0 GPM) with Various Ground Water Temperature
Chart is based on properly sized gas line
0.0
1.0
2.0
3.0
4.0
5.0
6.0
7.0
8.0
9.0
10.0
Out put Hot Water Temperature
O
u
t P
u
t H
o
t W
a
te
r G
P
M
40 F
50 F
60 F
70 F
40 F
6.1
5.6
5.2
4.9
4.6
4.3
4.1
3.8
3.7
3.3
3.0
2.9
2.8
2.7
2.6
2.5
50 F
7.3
6.6
6.1
5.6
5.2
4.9
4.6
4.3
4.1
3.7
3.3
3.2
3.0
2.9
2.8
2.7
60 F
9.0
8.1
7.3
6.6
6.1
5.6
4.8
4.8
4.6
4.1
3.7
3.5
3.3
3.2
3.0
2.9
70 F
9.0
9.0
9.0
8.1
7.3
6.6
4.8
4.8
4.8
4.6
4.1
3.8
3.7
3.5
3.3
3.2
100
105
110
115
120
125
130
135
140
150
160
165
170
175
180
185
Output
H
o
t Wa
ter
GPM
*When the set temperature is 130°F or higher, maximum flow rate is limited to 4.8 GPM.
