JAN/07/2003
RS850 OP 6
C. LED display:
LED Function LED Function
Off Disarmed Zone 1 / Warn-Away Trigger
Slow
Flash Armed 2 flashes...
pause Zone 2 / Trigger on Trunk/Hood
Flash Passive Starter Disable 3 flashes...
pause Zone 3 / Trigger on Door Switch
Fast Flash Passive Arming 4 flashes...
pause Zone 4 / Trigger on Shock
Sensor
On (Solid) Valet Mode 5 flashes...
pause
Zone 5 / Trigger on Ignition
Switch
D. CHIRP INDICATORS:
E. PARKING LIGHT:
Chirp Function Parking light Function
1 chirp Arm 1 flash Arm
2 chirps Disarm 2 flashes Disarm
3 chirps Defective Reminder 3 flashes Disarm / Triggered
4 chirps Disarm / Triggered 12 flashes Car Locator
6 chirps Car Locator Constant On Under Remote
Start
F. ALARM OPERATING CONDITION:
Siren / Horn
Parking
Light
LED Doors Starter Dome Light
1. Arming 1 or 3 Chirps 1 Flash
Slow
Flash
Locking Disable
2. Disarming 2 or 4 Chirps
2 or 3
Flashes
Unlocking
Turns on for 30
-second
3. Trigger Alarming Flashes
Slow
Flash
Disable Flashes
4. Passive
Starter
Disable
Fast
Flash
Disable
5. Panic Alarming Flashes Flashes
6. Car-Jacking Alarming Flashes Disable Flashes
7. Car Locator 6 Chirps 12 Flashes Locking
G. ACTIVE ARMING – LOCK & ARM:
1. Press button on the transmitter.
2. The siren will chirp once and parking light will flash once indicating that the
system is now armed. The vehicle door will lock upon arming when
interfaced with the security system.
